Liquid Silicone Rubber Rearview Mirror Cover Injection Molding Machine

  • 1
  • 2

Brand Name : Better

Model Number : Better 1200SD-3RT

Certification : CE、ISO

Place of Origin : GuangZhou，China

MOQ : 1 SET

Price : USD42000-USD82000per set

Payment Terms : T/T

Supply Ability : 20 sets per month

Delivery Time : 40 days

Packaging Details : Plastic film

Operation : Easy operation

Economic Benefits : Obvious--30-50% electricity can be saved

Warranty Time : 12 Months

Machinery Test Report : Provided

Contact Now

Liquid Silicone Rubber Rearview Mirror Cover Injection Molding Machine
BETTER 1600SD-3RT Vertical LSR Injection Molding Machine
Clamping Force160 tons
Size1500 × 730 mm
Max Mold Size720 × 660 mm
Min Mold Height120 mm
Mold Stroke300 mm
Max Daylight450 mm
Ejector Force4 tons
Thimble DiameterΦ30
Ejector Distance (Product)350 mm
Max Hydraulic Pressure140 kg/cm²
Cooling Water1500-1800 liters/hr
Electrothermal4 kW
Motor22 kW
Dimension (L×W×H)2.86 × 2.75 × 3.51/4.54 m
Weight11.4 tons
1200SD-3RT Key Features
  • High Productivity: Maximum time savings with no delays in vertical machines featuring rotary or shuttle table systems
  • Efficient Automation: Easy integration with complex production cells thanks to accessible mold area from all sides
  • Precision Insertion: Simple and precise insertion and holding of parts in cavities with horizontal mold parting line
  • Ergonomic Operation: Optimal table height eliminates the need for raised work platforms for operating staff
  • Short Handling Times: Safe and time-saving access to mold area with light curtain safety systems
  • Advanced Process Control: Electronic controller for hydraulic injection unit ensures excellent mold part quality and reproduction
  • Energy Efficiency: Low energy consumption through clamping pressure lock-in, low-friction guide elements, and intelligent servo hydraulic eco-drive
Liquid Silicone Rubber Rearview Mirror Cover Injection Molding Machine
Professional Service from BETTER
Pre-Sale Service
Provide investment budget and plant planning, along with complete solutions for machines and molds based on customer product requirements.
On-Sales Service
Comprehensive installation and new machine debugging services, including free training for your staff to operate and maintain equipment independently.
After-Sales Service
Timely technical support and problem resolution at customer sites, with priority product upgrading services for existing customers as required.
