Liquid silicone household vacuum cleaner sealing ring LSR high-precision injection molding machine

  • 1
  • 2

Brand Name : Better

Model Number : Better 4200-3V4R

Certification : CE、ISO

Place of Origin : GuangZhou，China

MOQ : 1 SET

Price : USD81999-USD119999per set

Payment Terms : T/T

Supply Ability : 5 sets per month

Delivery Time : 50 days

Packaging Details : Plastic film

Economic Benefits : Obvious--30-50% electricity can be saved

Motor : Servo Motor

Warranty Time : 12 Months

Style : Vertical

Contact Now

Liquid Silicone Household Vacuum Cleaner Sealing Ring LSR High-Precision Injection Molding Machine
Technical Specifications
Specification Value
Machine Model BETTER Vertical Rotary LSR Injection Molding Machine
Clamping Force 200 tons
Size Φ1600
Max Mold Size 600*600(750*500)mm
Min Mold Height 310+50mm
Mold Stroke 350mm
Max Daylight 600+50mm
Ejector Force 4.6 tons
Thimble Diameter Φ35
Ejector Distance (Product) 140(110)mm
Max Hydraulic Pressure 140kg/cm²
Cooling Water 1500-1800 liters/hr
Electrothermal 4kw
Motor 26kw
Dimension (L*W*H) 3.32*2.63*3.52/4.47
Weight 12 tons
Advanced Features
  • Precision Metering & Mixing: High-precision screw or plunger type metering pump driven by servo motor ensures accurate delivery and even mixing of A and B components with static mixer
  • Exquisite Mold Design: Multiple cavities with cold runner needle valve system suitable for all types of molds
  • Versatile Injection System: Can be used in combination with double injection or operated separately for flexible production
  • Automated Operation: Easy finished product removal and part embedding to save manpower
  • Advanced Control System: Full computer control with automatic programming for precise mold, injection, curing, mold opening, and stripping operations
  • Integration Ready: Compatible with robot and conveyor belt linkage for automated production lines
Applications
This vertical liquid silicone rubber injection machine is ideal for precision manufacturing in electronics, medical devices, baby products, and household appliances including vacuum cleaner sealing rings.
Liquid silicone household vacuum cleaner sealing ring LSR high-precision injection molding machine
